How to add a radius dimension

You can add the radius dimension of a circle or arc.

1. Select a cabinet, countertop or trim with a curve.




2. In the ANNOTATIONS ribbon, click Radius.




3. Point the curve where you want to display the radius dimension (the selected curve is highlighted in green), and left-click to display the dimension.




4. Design draws a line from the center to the arc annotated with the radius dimension.


5. The dimension label can be displayed inside or outside the countertop or cabinet. To switch between the two positions, right-click the dimension, and select Toggle Label.
